An exciting offline coating and curing system, providing a Kwik and EZ way to apply UV, aqueous, primer & specialty coatings to a wide variety of substrates. Whether paper or plastic; digital output or offset, each job will have the visual appeal, lasting durability, protection and rub resistant finish that your customers expect!

• Automatic double-sheet detector
• Stream Feeder with continuous pre-load
• Removable cylinder grippers
• Touch Screen Control Panel
• Equipped with Interlocking safety guards & E-stops
• Circumferential and Lateral registration for accurate spot coating
• Flood & spot coat as well as spot not coat (allowing areas to be free of coating for variable data printing)
• Includes Kompac Kwik Stack - automated receding stacker
• Kwik release blanket bars (for fast job changes)
• Auto coating level pump & sensor (automatically replenishes coating when it is low)
• Patented Kompac Air Delivery System provides 'non-contact' delivery of the coated sheet

• Provides on-the-fly coating adjustments
• Produces the highest quality gloss and a perfect finish every time
• EZ to clean and change coatings - With the patented "Kompac Vac" and our environmentally friendly UV Klean, coating change and clean up takes 5 minutes

• Medium - Large Offset Printers
• Packaging
• Converters
• Xeikon & other larger digital presses

Maximum Sheet Size: 22" x 31.5"560mm x 800mm
Maximum Coating Area: 21.65" x 31.5"550mm x 800mm
Minimum Sheet Size: 10" x 12"254mm x 305mm
Sheets per hour (sph): up to 6000up to 6000
Stock Weight: 3pt. to 24pt.60g/m² to 600g/m²
Curing Selections: 125 / 200 / 300w125 / 200 / 300w
Dimensions:  6' x 20'1.8m x 6m
